Ankyron CD63_HUMAN Clone AW40508

HeLa cells were stained using 10 µg V5-tagged Ankyron and anti-V5 antibody conjugated with APC (red) in Permeabilization Staining Buffer (RPMI 1640 + 10 % human serum + 0.5 % saponin, counterstaining nuclei with DAPI (blue). Image captured by epifluorescence microscopy.

HUVEC were stained using 1.4 µg V5-tagged Ankyron and anti-V5 antibody conjugated with APC (red) in Permeabilisation Staining Buffer (RPMI 1640 + 10 % human serum + 0.5 % saponin), counterstaining nuclei with DAPI (blue) and F-actin with Phalloidin. Inset: negative control of anti-V5 APC antibody alone and F-actin staining.

Immunohistochemical analysis of paraffin-embedded human kidney using 10 μg/ml V5-tagged Ankyron and anti-V5 HRP (1 in 500), detecting with DAB (brown) and counterstaining nuclei with haematoxylin (blue-purple). Heat-mediated antigen retrieval with Leica Tris-EDTA buffer (pH9), 40 min.

Immunohistochemical analysis of paraffin-embedded human kidney using 10 μg/ml V5-tagged Ankyron and anti-V5 HRP (1 in 500), detecting with DAB (brown) and counterstaining nuclei with haematoxylin (blue-purple). Heat-mediated antigen retrieval with Leica EDTA buffer (pH9), 40 min.

Binding assay determination of the signal to noise ratio (SNR) of V5-labeled Ankyrons® AW40508 binding to 0.5 picomoles of immobilised CD63_HUMAN, over a background (BG) of non-cognate target protein. The Ankyron was pre-conjugated with the ProImmune Anti-V5 HRP label reagent before detection with a chemiluminescence substrate.
